We offer high performance, low power, scalable IPs targeting ASIC and FPGA. LDPC Encoder is our first IP, with more to come.

Support for all codes defined in 5G NR standard (3GPP TS 38.212)
Coded throughput up to 68Gb/S for ASIC and 18.5Gb/s for FPGA
Easily customizable as per request by the customer
Provide separate optimized designs for filler bit insertion at the input and puncturing and filler bit removal at the output.

For FPGA:

Clock frequency at 270MHz

Coded throughput up to 18.5Gb/s

Latency : < 1.384us

Flop counts : 6381

LUT : 14k

BRAM : 5.5

For ASIC*:

Clock frequency at 1GHz

Coded throughput up to 68Gb/s

Latency : < 0.374us

Flop count: 7000

SRAM : 3.19KB

*Note: the above data are estimated.
